INPUT IMPEDANCE:        100Kohm (RCA)

           OUTPUT IMPEDANCE:        4 ohm-8 ohm

                    OUTPUT POWER:        12W (ULTRALINEAR) CLASS AB P-P

                 DAMPING FACTOR:         >3

   FREQUENCY RESPONSE:         20Hz-20KHz  -1dB

                                        T.H.D.:         <1% 20Hz-20KHz (RCA OUTPUT)

                             TOTAL GAIN:         28dB

               INPUT SENSITIVITY:         300mV-600mV

                 Singal/Noise Ratio:          >90dB  (HUM NOISE <1.5mV)

             CHANNEL BALANCE:        <1dB  20Hz-20KHz  (MAX.  VOLUME)

         CHANNEL SEPRATION:        >65dB  20Hz-20KHz

            TUBE  COMPLEMENT:        6P6P (6V6) x 4

                                                 6N8P(6SN7) x 2

                                                             12AX7(ECC83) x 1

       POWER REQUIREMENT:        AC 220V or 110V±5%. 50~60Hz

                              DIMENSION:        420mm x 310mm x 245mm (W×L×H)

                       N.W.: 10.50 KGS         G.W.: 13 KGS
